Honeywell VOYAGER 1202G BF User Manual

3 - 10
Alarm Duration
To set the the length of time you want the Out-of-Range alarm to sound, scan the following bar code and then set the time-
out duration (from 0-3000 seconds) by scanning digits on the Programming Chart inside the back cover, then scanning
Save. Default = 1 sec.
Scanner Power Time-Out Timer
Note: Scanner Power Time-out Timer only applies to cordless systems. It does not apply to corded scanners.
When there is no activity within a specified time period, the scanner enters low power mode. Scan the appropriate scanner
power time-out bar code to change the time-out duration (in seconds).
If the scanner is not activated during the timer interval, the scanner goes into power down mode. Whenever the scanner is acti-
vated, the timer is reset. If Scanning While in Base Cradle (page 3-6) is disabled, the scanner will still go into power down
mode. Default = 3600 seconds.
Note: When the scanner is in power down mode, press the scanner’s button to power the unit back up. There will be a set of
power up beeps and a delay of up to a few seconds for the radio to join. The scanner will then be ready to use.
RangeGate
If you need RangeGate functionality, the scanner can be programmed for Automatic Batch Mode (page 3-11), which offers
equivalent capabilities.
Scanner Alarm Duration
Timer Off
200 seconds
400 seconds
900 seconds
* 3600 seconds
7200 seconds

Honeywell VOYAGER 1202G BF Specifications

General

Product Name	Honeywell VOYAGER 1202G BF
Category	Barcode Reader
Scanner Type	Laser
Battery-Free Technology	Yes
Scan Rate	100 scans per second
Decode Capability	1D Barcodes
Interface	USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Weight	180g (6.3 oz)
Dimensions	180 mm x 66 mm x 92 mm (7.1 in x 2.6 in x 3.6 in)
Connectivity	Bluetooth
Radio Range	Up to 10 meters
Scan Pattern	Single Line
Humidity	5% to 95% relative humidity, non-condensing
Drop Specification	Withstands 30 drops to concrete from 1.5 m (5 ft)
Power Source	Battery-Free with Supercapacitor
Resolution	1D: 4 mil (0.102 mm), 2D: 6.7 mil (0.169mm)
