Honeywell VOYAGER 1202G BF User Manual

10 - 3
Resetting the Factory Defaults
If you aren’t sure what programming options are in your scanner, or you’ve changed some options and want to restore the scan-
ner to factory default settings, first scan the Remove Custom Defaults bar code, then scan Activate Defaults. Power cycle
the scanner to reset it to the factory default settings.
Note: If using a cordless system, scanning the Activate Defaults bar code also causes both the scanner and the base or Access
Point to perform a reset and become unlinked. The scanner must be placed in its base to re-establish the link before any
setup codes are entered. If using an Access Point, the linking bar code must be scanned. See Cordless System
Operation (Voyager 1202g) beginning on page 3-1 or Cordless System Operation (Voyager 1202g-BF) beginning on page
4-1 for additional information.
The Serial Programming Commands, beginning on page 11-1 list the factory default settings for each of the commands (indi-
cated by an asterisk (*) on the programming pages).
This selection erases all your settings and resets the scanner to the original factory defaults.
!
Remove Custom Defaults
Activate Defaults

Honeywell VOYAGER 1202G BF Specifications

General

Product Name	Honeywell VOYAGER 1202G BF
Category	Barcode Reader
Scanner Type	Laser
Battery-Free Technology	Yes
Scan Rate	100 scans per second
Decode Capability	1D Barcodes
Interface	USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Weight	180g (6.3 oz)
Dimensions	180 mm x 66 mm x 92 mm (7.1 in x 2.6 in x 3.6 in)
Connectivity	Bluetooth
Radio Range	Up to 10 meters
Scan Pattern	Single Line
Humidity	5% to 95% relative humidity, non-condensing
Drop Specification	Withstands 30 drops to concrete from 1.5 m (5 ft)
Power Source	Battery-Free with Supercapacitor
Resolution	1D: 4 mil (0.102 mm), 2D: 6.7 mil (0.169mm)
