Honeywell Voyager 1470g User Manual

198 Voyager XP User Guide
Voyager XP 1472g Cordless Scanner Product
Specifications
Image Size 1040 x 720 pixels
Scan Performance
Pitch, Skew ± 65°, ± 70°
Motion Tolerance:
Presentation Mode up to 70cm per second for 13 mil UPC
Print Contrast 20%
Parameter Specification
Parameter Specification
Mechanical
Height 6.8 in. (17.3cm)
Length 3.2 in. (8.2cm)
Width 2.5 in. (6.2cm)
Weight 7.3 oz. (210g)
Electrical
Battery:
Lithium Ion 2400 mAH lithium-ion
Number of Scans Up to 50,000 per charge
Expected Hours of Operation 14
Expected Charge Time 4.5 hours
Illumination White color (CCT 2700K)
Aiming Red color, 624nm peak wavelength
Radio
Frequency 2.4 to 2.5 GHz (ISM Band) Frequency Hopping Bluetooth
v.4.2
Range 330 ft. (100 m) typical
Data Rate Up to 1 MBps
Environmental
Operating Temperature 32° F to 122° F (0° C to 50° C)
Storage Temperature (with battery) -4°F to 95°F (-20°C to 35°C) storage for 90 days
-4°F to 68°F (-20°C to 20°C) storage for 1 year
Storage Temperature (without
battery)
-40° F to 140° F (-40° C to 60° C)
Humidity Up to 95% non-condensing
Drop Operational after 30 drops to concrete from 5.9 ft. (1.8 m)
Environmental Sealing IP52

Honeywell Voyager 1470g Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Sealing	IP40
Motion Tolerance	Up to 70 cm/s (27.6 in/s) for 13 mil UPC at optimal focus
Storage Temperature	-40°C to 60°C (-40°F to 140°F)
Weight	130 g (4.6 oz)
Humidity	0% to 95% relative humidity, non-condensing
Scan Pattern	Omnidirectional
Connectivity	USB, RS-232, Keyboard Wedge
Decode Capability	Reads standard 1D
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Light Levels	0 to 100, 000 lux
Dimensions	62 mm x 169 mm x 82 mm (2.5 in x 6.6 in x 3.2 in)
Light Source	LED
