Honeywell Voyager 1470g User Manual

52 Voyager XP User Guide
Scanner Power Time-Out Timer
Note: Scanner Power Time-out Timer only applies to cordless systems. It does not apply to
corded scanners.
When there is no activity within a specified time period, the scanner enters low
power mode. Scan the appropriate scanner power time-out barcode to change the
time-out duration (in seconds).
Note: Scanning zero (0) is the equivalent of setting no time-out.
If there are no trigger pulls during the timer interval, the scanner goes into power
down mode. Whenever the trigger is enabled, the timer is reset. If the scanner is
placed in the charge base cradle and the battery is in the process of being charged,
the scanner will not go into power down mode. Default = 3600 seconds.
Note: When the scanner is in power down mode, pull the trigger to power the unit back up.
There will be a set of power up beeps and a delay of up to a few seconds for the radio
to join. The scanner will then be ready to use.
Scanner Alarm Type
0 seconds
200 seconds
400 seconds
900 seconds
* 3600 seconds
7200 seconds

Honeywell Voyager 1470g Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Environmental Sealing	IP40
Motion Tolerance	Up to 70 cm/s (27.6 in/s) for 13 mil UPC at optimal focus
Storage Temperature	-40°C to 60°C (-40°F to 140°F)
Weight	130 g (4.6 oz)
Humidity	0% to 95% relative humidity, non-condensing
Scan Pattern	Omnidirectional
Connectivity	USB, RS-232, Keyboard Wedge
Decode Capability	Reads standard 1D
Drop Specification	Withstands multiple 1.5 m (5 ft) drops to concrete
Light Levels	0 to 100, 000 lux
Dimensions	62 mm x 169 mm x 82 mm (2.5 in x 6.6 in x 3.2 in)
Light Source	LED
