3-51
P
erformance T
ests
SPDH Receiver Monitor Levels (Options UKJ
, [USA], UKL, [USC], UKN,
[USE])
Procedur
e
1.
Recall the HP 37717C DEF
A
UL
T SETTINGS as shown on 3-2.
2.
Connect the equipment as sho
wn in Figure 3-23.
Figure 3-23
SPDH Receiv
er Monitor Input
Fixed Attenuator (Qty 2)
: HP 8491A Option 006 (6dB; 50
Ω
)
Fixed Attenuator (Qty 2)
: HP 8491A Option 003 (3dB; 50
Ω
)
Matching Pad 75/50
Ω
(7.6dB loss)
: HP 11852B
Matching Pad 50/75
Ω
(4.2dB loss)
: HP 11852B
T
able 3- 2
continued
159
161
