3-221
Performance Tests
ETSI/ANSI Transmitter Output Level and Waveshape (Option 110)
ETSI/ANSI Transmitter Output Level and Waveshape
(Option 110)
Specification
Description
This test ensures the transmitter output level and pulse shape meet the required spec-
ifications at E1,E3,DS1 and DS3 rates. The Transmitter output is connected to an os-
cilloscope and the waveshape compared with the predefined masks stored in the
oscilloscope memory. The signal levels are also measured using the oscilloscope.
Rate Frequency Level Waveshape
DSX-1 1.544Mb/s 3.0V +/-20% Fits mask T1.102-1993
DS1-LO 1.544Mb/s As DSX-1 with 655'
ABAM Cable
DS3-HI 44.736Mb/s 0.9V pk (nominal)
DSX-3 44.736Mb/s 560mV pk (nomi-
nal)
Fits mask T1.102-1993
DS3-900 44.736Mb/s 330mV pk (nomi-
nal)
E1 (bal) 2.048Mb/s 3.00V +/-10% As per ITU rec G703
E1 (unbal) 2.048Mb/s 2.37V +/-10% As per ITU rec G703
E3 34.368Mb/s 1.0V +/-10% As per ITU rec G703
