3-132
Performance Tests
Transmitted Jitter/Wander Amplitude Accuracy (Option A3K [A3Q])
Transmitted Jitter/Wander Amplitude Accuracy (Option
A3K [A3Q])
Specifications
Jitter Generation:
Amplitude Range:
Data Rates 2.048 Mb/s, 8.448 Mb/s, 34.368 Mb/s, 139.264 Mb/s,
155.52 Mb/s (STM-1), 622.08 Mb/s (STM-4)
Overall Accuracy ± 5% ± range accuracy ± intrinsic jitter
± High Frequency accuracy (STM-1E only)
Range 1 ± 0.01 UI
Range 10 ± 0.1 UI
Range 50 ± 0.5 UI
Range 80 ± 1.0 UI
Range 200 ± 2.0 UI
Intrinsic Jitter 2 Mb/s ± 0.02 UI
Intrinsic Jitter 8 Mb/s ± 0.02 UI
Intrinsic Jitter 34 Mb/s ± 0.03 UI
Intrinsic Jitter 140 Mb/s 200 Hz to 5 kHz - ± 0.10 UI
5 kHz to 10 kHz - ± 0.05 UI
>10 kHz - ± 0.02 UI
Intrinsic Jitter 155.52 Mb/s < 10 kHz - ± 0.04 UI; > 10 kHz - ± 0.03 UI
Intrinsic Jitter 622.08 Mb/s ± 0.1 UI
High Frequency (STM-1E only) ± 0.0 to 0.2 UI, >1.3 MHz - typically ± 10%
> 0.2 UI, >1.3 MHz - typically ± 20%
