13 Checking Before Leaving the Site
13.1 (Optional) Installing Front and Rear Sealing
Plates
Procedure
Step 1 Install sealing plates on the front and rear of the ICC800/ESC800 base.
Figure 13-1 Installing front and rear sealing plates
----End
PowerCube 1000 (STC, Saudi Arabia, ICC800-A1-C2,
ESC800-A1)
Installation Guide 13 Checking Before Leaving the Site
Issue 02 (2021-09-28) Copyright © Huawei Technologies Co., Ltd. 142
