5 Installation Preparations
5.1 Preparing Cables
All cables must comply with local laws, regulations, and standards as well as
customer requirements.
The cross-sectional area of a power cable depends on the current that will
ow
through the cable and the voltage drop allowed for the cable.
The cable sizes are for reference only.
Table 5-1 Preparing cables
Cable Type
Maximum
Current
(A)
Minimum Cross-
Sectional Area (mm
2
)
Maximum Cross-
Sectional Area (mm
2
)
Ground cable - 16 35
AC input power
cable (three-
phase four-wire)
L wire 80 16 35
N wire 80 16 35
DC output power
cable
- 63 10 25
125 25 35
Battery cable - 125 25 35
1. The size data in the table is the cable sizes applicable when the ambient temperature is
30°C (in air) and only cables in a single loop are involved.
2. When the ambient temperature is not 30°C or cables in multiple loops are routed
together, use cables with larger cross-sectional areas if the cabling distance is long.
3. Power cables should be able to withstand at least 105°C.
PowerCube 1000 (STC, Saudi Arabia, ICC800-A1-C2,
ESC800-A1)
Installation Guide 5 Installation Preparations
Issue 02 (2021-09-28) Copyright © Huawei Technologies Co., Ltd. 64
