Item 4G Antenna
Storage temperature –40°C to +85°C, typical value 25°C
Relative humidity 0%–95% RH (non-condensing), typical value: 50%
Altitude 0–4000 m (When the altitude ranges from 0 m to 4000
m, the operating temperature decreases by 1°C for
each additional 200 m.)
Dimensions (H x W x
D)
Height ≤136 mm, width ≤60 mm
Weight ≤500 g
Frequency range 698 MHz–960 MHz or 1710 MHz–2700 MHz
Polarization mode Vertical polarization
Standing wave ratio
(SWR)
< 2.2
Maximum input
power
10 W
IP rating IP65
MTBF 100,000 hours (at 25°C)
3.19 Digital Temperature and Humidity Sensor
A digital temperature and humidity sensor detects the indoor ambient
temperature and humidity in real time.
Figure 3-35 Appearance 1
Figure 3-36 Appearance 2
PowerCube 1000 (STC, Saudi Arabia, ICC800-A1-C2,
ESC800-A1)
Installation Guide 3 Component
Issue 02 (2021-09-28) Copyright © Huawei Technologies Co., Ltd. 53
