Chapter 1 The IBM 6400 Series Printer Family
Hanzi Printers
IBM 6400-C05 and 6400-C5P printers have shuttle assemblies, hammer
springs, and software specially designed to print the GB character set and
Song typeface used in the People’s Republic of China. These printers can mix
ASCII and Hanzi characters on the same line, with ASCII characters
occupying half the width of Hanzi character cells. Because of the density and
Table 1. The IBM 6400 Series Printer Family
Model
Number
Print
Speed
Enclosure
Hammer
Bank
Data
Controller
Clock
1
6400-004 475 lpm Cabinet 28 Hammers 25 MHz
6400-04P 475 lpm Pedestal 28 Hammers 25 MHz
6400-005 500 lpm Cabinet 28 Hammers 25 MHz
6400-05P 500 lpm Pedestal 28 Hammers 25 MHz
6400-050 500 lpm Cabinet 28 Hammers 40 MHz
6400-P50 500 lpm Pedestal 28 Hammers 40 MHz
6400-008 800 lpm Cabinet 49 Hammers 25 MHz
6400-08P 800 lpm Pedestal 49 Hammers 25 MHz
6400-009 900 lpm Cabinet 49 Hammers 25 MHz
6400-09P 900 lpm Pedestal 49 Hammers 25 MHz
6400-010 1000 lpm Cabinet 60 Hammers 40 MHz
6400-P10 1000 lpm Pedestal 60 Hammers 40 MHz
6400-012 1200 lpm Cabinet 91 Hammers 25 MHz
6400-014 1400 lpm Cabinet 91 Hammers 40 MHz
6400-015 1500 lpm Cabinet 102 Hammers 40 MHz
6400-C05 585 lpm Cabinet 91 Hammers 40 MHz
6400-C5P 585 lpm Pedestal 91 Hammers 40 MHz
1
The microprocessor of the Data Controller unit on the CMX controller
board runs at 25 MHz or 40 MHz, depending on printer model. This means
there are two kinds of CMX controller board for IBM 6400 printers, used as
shown in this table. The 40 MHz controller board, however, is backwards
compatible in all models that use the 25 MHz board.
