Illustrations Of Printer Components
249
Section II: Illustrated Parts Lists
Only field-replaceable spares are given part numbers in the illustrated parts
lists. Part numbers are not listed for common fasteners and attachment
hardware. Items marked “Ref” in the illustrations refer to parts that are not
spared or are part of another assembly.
Illustrations Of Printer Components
Figure 40. Top Cover, Doors, and Casters, Cabinet Model ............ page 250
Figure 41. Paper Stacker and Chains............................................. page 252
Figure 42. Control Panel and Cabinet Details................................. page 254
Figure 43. Pedestal Details ............................................................. page 256
Figure 44. Inside Covers, Cabinet Model........................................ page 258
Figure 45. Inside Covers and Card Cage, Pedestal Model............. page 260
Figure 46. Card Cage Detail, Pedestal Model................................. page 262
Figure 47. Print Mechanism and Circuit Boards: Early Models....... page 264
Figure 48. Print Mechanism and Circuit Boards: Later Models....... page 268
Figure 49. Magnetic Pickup Unit (MPU) and Extension Spring....... page 272
Figure 50. Tractor Shafts ................................................................ page 274
Figure 51. Platen............................................................................. page 276
Figure 52. Motors, Card Cage Fan, and Paper Detector Switch..... page 278
Figure 53. Circuit Breaker ............................................................... page 280
Figure 54. Expansion Coax/Twinax Board...................................... page 282
Figure 55. Ethernet Interface Assemblies....................................... page 284
