186
Chapter 7 Section I: Replacement Procedures
Section I: Replacement Procedures
This section contains removal/installation procedures for components that are
replaceable at the field service maintenance level. These procedures are
listed below.
IMPORTANT
Do not attempt field repairs of electronic components or assemblies.
Replace a malfunctioning electronic assembly with an operational
spare. Most electronic problems are corrected by replacing the circuit
board, sensor, or cable that causes the fault indication. The same is true
of failures traced to the hammer bank coils and electronics: you must
replace the entire shuttle frame assembly. It is not field repairable.
(Hammer spring assemblies are the only replaceable components of the
shuttle frame assembly.)
List Of Procedures
Belt, Paper Feed Timing ................................................................. page 188
Belt, Platen Open............................................................................ page 189
Circuit Board: Controller.................................................................. page 190
Circuit Board: Power Supply ........................................................... page 192
Circuit Breaker ................................................................................ page 193
Coax/Twinax Multi-Platform Interface ............................................. page 194
Connector Shells............................................................................. page 195
Connector Stiffening Clips............................................................... page 198
Cover Assembly, Hammer Bank / Ribbon Mask ............................. page 200
Cover Assembly, Shuttle................................................................. page 203
Cover Assembly, Top, Pedestal Model........................................... page 204
Dashpot........................................................................................... page 205
Doors, Cabinet, Reversing.............................................................. page 206
Ethernet Interface Assemblies ........................................................ page 207
Fan Assembly, Cabinet Exhaust..................................................... page 208
Fan Assembly, Card Cage.............................................................. page 209
Fan Assembly, Hammer Bank ........................................................ page 210
Hammer Spring Assembly .............................................................. page 211
IBM Coax/Twinax Expansion Board................................................ page 215
Magnetic Pick-up (MPU) Assembly................................................. page 216
Memory and Security Modules........................................................ page 217
Motor Assembly, Paper Feed.......................................................... page 221
Motor Assembly, Platen Open ........................................................ page 223
