Chapter 7 Section I: Replacement Procedures
Tractor (L/R)
Removal
1. Prepare the printer for maintenance (page 152).
2. Remove the splined shaft (page 239).
3. Remove the support shaft (page 241).
4. Remove the tractors.
Installation
1. Using the replacement tractors, install the support shaft (page 241).
2. Install the splined shaft (page 239).
3. Return the printer to normal operation (page 153).
