IBM 6400 Maintenance Information Manual

140
Chapter 5 Hex Code Printout
Hex Code Printout
A hex code printout (“hex dump”) prints every ASCII character received from
the host computer with its corresponding two-digit hexadecimal code. Hex
dumps can be used to troubleshoot printer data reception problems by
comparing the printed hex data to the data sent from the host.
In a hex dump, every character is printed as its assigned ASCII symbol and
as the hexadecimal value of the character. A character that does not have a
printed symbol (for example, a control character) is printed as a period (.) and
the hex value of the control character.
If the printer is using a parallel interface, the letter p before a hex code
indicates an active Paper Instruction (PI) line and a blank space before a hex
code indicates an inactive PI line.
To convert an ASCII character to its corresponding hex code, or vice-versa,
refer to the ASCII code chart on page 142.
Step Press Displayed Result Notes
1. Install the ribbon, load paper, and power on the printer.
2.
NOT READY
Puts printer in NOT
READY mode.
3.
OPERATOR MENU
UNLOCKED
Unlocking ENTER key
gives you access to the
configuration menus.
4.
OPERATOR MENU
PRINTER CONTROL
First of series of
configuration menus.
5.
PRINTER CONTROL
INTERFACE SELECTION
Moves down to Interface
Selection option.
6.
PRINTER CONTROL
HEX PRINT MODE
Moves down to the Hex
Print Mode option.
7.
HEX PRINT MODE
DISABLE*
Moves down to Disable,
the active option.
8.
HEX PRINT MODE
ENABLE
Moves to Enable, the
alternate option.
9.
HEX PRINT MODE
ENABLE*
Asterisk (*) indicates this
choice is now active.
10.
NOT READY
Returns printer to NOT
READY mode.
Stop
+
Scroll↑ Scroll↓
Menu
Enter
UNTIL
Scroll↑
Enter
Scroll↑
Enter
Stop
