Dashpot
205
Dashpot
This procedure applies only to cabinet models.
Removal
1. Prepare the printer for maintenance (page 152).
2. Open the printer cover.
3. Open the floor cabinet rear door.
4. Pry back the spring retaining clips (page 254, Figure 42).
5. Remove the dashpot from the ball studs.
Installation
ATTENTION
The dashpot must be installed with the large cylinder uppermost.
1. Position the dashpot against the ball studs on the upper and lower
brackets (page 254, Figure 42). The large cylinder must be uppermost.
2. Push the dashpot onto the ball joints and install the spring clips.
3. Close the printer cover. If necessary, adjust the position of the ball joint
stud in the lower bracket to achieve smooth and complete closure.
4. Return the printer to normal operation (page 153).
<3> Two persons may be required to do this procedure. Prop or
hold the top cover securely open while disengaging the
dashpot.
CAUTION
