Cleaning The Card Cage Fan Assembly
33
Cleaning The Card Cage Fan Assembly
1. Cabinet Models: Remove the paper guide assembly (page 229).
Pedestal Model: Remove the top cover assembly (page 204).
2. Vacuum the card cage fan assembly and surrounding areas to remove
paper particles, dust, and lint. (See Figure 7.)
3. Cabinet Models: Install the paper guide assembly (page 229).
Pedestal Model: Install the top cover assembly (page 204).
4. Close the printer cover.
5. Connect the AC power cord to the power source.
Figure 7. Cleaning the Card Cage Fan Assembly
NOTE: Cabinet model shown.
Procedure is the same for
pedestal model.
1
