7 Replacement Procedures
And Illustrated Parts Lists
Organization Of This Chapter
This chapter is divided into two sections.
• Section I: Replacement Procedures
This section contains written procedures for removing and installing
components that are replaceable at the field service level of maintenance.
The procedures in this section refer you to the illustrations in Section II.
Section I begins on page 186.
• Section II: Illustrated Parts Lists
This section contains drawings of all assemblies comprising the printer.
On the page facing each illustration is a list of the illustrated parts and
their part numbers.
Section II begins on page 249.
IMPORTANT
The components specified in this chapter are field replaceable units
(FRUs). FRUs must
be repaired at the factory. Do not attempt field repair
of these items.
