List Of Adjustments
155
Legend:
1) Timing Belt Shield
2) Motor Mount Bolt (2)
3) Paper Feed Drive Motor
4) Splined Shaft
Figure 21. Paper Feed Timing Belt Adjustment
Direction of Force
1
2
3
4
2
$
$
