Table 13. Weight of an enclosure with 92 SAS drives
FRU description
Approximate weigh per unit
Maximum
supported
Approximate extra weight
kg lb kg lb
2.5-inch tier 0
flash drive
2.5-inch tier 1
flash drive
0.224 0.494 92 20.608 45.433
2.5-inch hard disk
drive
0.304 0.670 92 27.968 61.659
3.5-inch
Near-Line SAS
hard disk drive
0.876 1.931 92 80.592 177.675
As you install or replace FRUs, the overall weight of the expansion enclosure
increases. For example, Table 14 shows the weight progression as different
combinations of FRUs are installed.
Table 14. Enclosure weight as FRUs are installed
Enclosure assembly Approximate weight
FRUs installed FRUs not installed kg lb
v Enclosure (01LJ112) v Secondary expansion
modules
v Fascia (1U and 4U)
v PSUs
v Expansion canisters
v Fan modules
v Fan interface board
v Display assembly
v Drives
v Cover
42.5 93.7
v Enclosure (01LJ112)
v Secondary expansion
modules
v Fascia (1U and 4U)
v PSUs
v Expansion canisters
v Fan modules
v Fan interface board
v Display assembly
v Drives
v Cover
44.3 97.7
v Enclosure (01LJ112)
v Secondary expansion
modules
v Fascia (1U and 4U)
v PSUs
v Expansion canisters
v Fan modules
v Fan interface board
v Display assembly
v Drives
v Cover
58 127.9
48 SAN Volume Controller: Model 2145-SV1 Hardware Installation Guide
