Icom IC-9100 User Manual

102
8
DV MODE OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Making a Zone CQ/Gateway CQ call
NOTE: The settings are the same between Zone
CQ and Gateway CQ call.
CS CD R>CS UR DSET
D1
≈ GRP3
UR:IKOMA−43
Repeater selection screen
Appear
[TRANSMIT][TS•GRP]
[MAIN DIAL]
MAIN Band TX/RX indicator
The selected channel number blinks.
When a blank channel is selected.
()1ch ARAS CQCQ
MW
DV446.00000
()5ch
MW
————————— . — ————
D Storing the set data
Youcansavethetemporarysettinginthefollowing
manner.
q After setting, push [MW] to enter the memory select
write mode , then rotate [MAIN DIAL] or [M-CH] to
select the desired Memory channel, Call channel or
Program scan edge channel.
w H old down [MW] for 1 second to store the setting.
t Rotate [MAIN DIAL] to select a desired destination
repeater.
 •Firstselecting therepeatercall sign groupmakes it
more convenient, if you have programmed repeaters
into Groups. (p. 93)
y Push [PTT] on the microphone to transmit. (or
[TRANSMIT] on the transceiver)
 •TheMAINBandTX/RXindicatorlightsred.
u Release [PTT] to receive. (or push [TRANSMIT]
again)
• Calling CQ through a link repeater in the same
zone (Zone CQ)
My call sign：
JA3YUA
Repeater q ： NARA43 (JP3YHL)
Repeater r ： IKOMA43 (JP3YHJ)
CQ
q w e r
Area
Zone
• Calling CQ through a gateway repeater (Gateway
CQ)
Repeater e ：
Repeater y ：
CQ
q w e r
t y u i
MY call sign：
JA3YUA
Gateway
Gateway
Area
Zone A
Zone B
HIRANO43
(JP3YHH)
IcomUSA
(N7IH)
