DUP Offset 18.
Settheoffset*forduplexoperation.Youcansetthe
repeater offset for each band.
*The difference between transmit and receive frequencies.
➥ When you select this item, hold down [BAND](MAIN/
SUB) for 1 second to select the desired frequency
band. Then, rotate [MAIN DIAL] to set the offset.
•Thefrequencyoffsetcanbesettobetween0.0000MHz
and 9.9999 MHz*.
*99.9999 MHz for the 1200 MHz frequency band.
The default value may differ, depending on the se-
lected frequency band and transceiver version.
NOTE:
•YoucanusethissettingonlywhentheSplitfunc-
tion is OFF for the HF/50 MHz frequency band.
•“-.---.-”isdisplayedwhenablankmemorychannel
is selected, or the satellite mode is ON.
The optional UX-9100 is required for 1200 MHz frequency
band operation.
One Touch Repeater 19. (Default: DUP–)
Set the one touch repeater shift direction.
•DUP–:Thetransmitfrequencyshiftsdownfromthe
receive frequency by the offset amount.
•DUP+:The transmit frequencyshifts up from the
receive frequency by the offset amount.
Auto Repeater 20.
(Default: ON–1 ; for U.S.A. version
ON ; for Korea version)
(Only U.S.A. and Korea versions)
Set the Auto Repeater function ON or OFF.
To activate the Auto Repeater function, first program the
auto repeater frequency range, then select ON. (p. 67)
U.S.A. version:
•ON–1:Activatesduplexonly.
•ON–2:Activatesduplexandtone.
•OFF :AutorepeaterfunctionisturnedOFF.
Korea version:
•ON :Activatesduplexandtone.
•OFF :AutorepeaterfunctionisturnedOFF.
Tuner (Auto Start) 21. (Default: OFF)
Turn the Automatic Antenna Tuner function ON or
OFF. This function is for only the HF bands.
•OFF:TheinternalantennatunerremainsOFFeven
when the SWR is high.
•ON :Theinternalantennatunerautomaticallystarts
tuning when the SWR is high, even if the tuner
is turned OFF.
Tuner (PTT Start) 22. (Default: OFF)
Whenever you push [PTT], the internal or external an-
tenna tuner automatically starts tuning if the operat-
ingfrequencyhaschangedbymorethan1%fromthe
last-tuned frequency.
•OFF:Tuningstartsonlywhen[TUNER]ispushed.
•ON :(Internal antennatuner)Tuningstartswhen
you push [PTT] on a new frequency, if the in-
ternal antenna tuner is ON.
(External antenna tuner) Tuning always starts
when you push [PTT] on a new frequency, re-
gardless of whether the external antenna tuner
is ON or OFF.
Tuner Preset Clear23.
Select the desired antenna.
The selected antenna’s preset memory* is cleared by
holding down [CLR](F-4) for 1 second.
* The variable capacitor settings are memorized as a
preset point for each frequency range (100 kHz steps)
after the tuner matches an antenna.
•CLRANT1:Thepresetmemoryof[ANT1]’santenna
is cleared.
•CLRANT2:Thepresetmemoryof[ANT2]’santenna
is cleared.
[ANT] Switch 24. (Default: Auto)
Set the antenna switch function to Auto, Manual or OFF.
When you change the operating frequency on the HF/
50 MHz frequency band, this function will automatically
select the correct antenna, or you must do it manually.
•OFF :[ANT•METER] does not function. The
[ANT1] connector is always selected.
•Manual :Youmustmanuallychangetheantennaby
pushing[ANT•METER].
•Auto :Theantennamemorizedbythebandmem-
oryisautomaticallyselected.Youcanalso
manually change the antenna by pushing
[ANT•METER].
■ Set mode description (Continued)
