Icom IC-9100 User Manual

189
18
CONTROL COMMAND
Cmd. Sub cmd. Data Description
1A 05 0146 00 Send/read DR Call Sign Popup OFF
01 Send/read DR Call Sign Popup ON
0147 00 Send/read Opening Call Sign OFF
01 Send/read Opening Call Sign ON
0148 00 Send/read BK function OFF
01 Send/read BK function ON
0149 00 Send/read EMR mode OFF
01 Send/read EMR mode ON
0150 0000 to
0255
Send/read EMR AF Level
(0000=0%to0255=100%)
0151 00 Send/read 4800 bps selection for GPS
Receiver Baud
01 Send/read 9600 bps selection for GPS
Receiver Baud
0152 00 Send/read ddd˚mm.mm’ selection for Po-
sition Format
01 Send/read ddd˚mm’ss” selection for Posi-
tion Format
0153 00 Send/read Meter selection for the display-
ing unit
01 Send/read Feet/Mile selection for the dis-
playing unit
0154 00 Send/read North REF selection for com-
pass direction
01 Send/read South REF selection for com-
pass direction
0155 see p. 192 Send/read UTC Offset
0156 00 Send/read GPS Indicator OFF
01 Send/read GPS Indicator ON
0157 00 Send/readGPSselectionforMYPosition
input method
01 Send/readManualselectionforMYPosi-
tion input method
0158 see p. 192 Send/read my position information
0159 see p. 193 Send/read Alarm Area1
0160 00 Send/read Limited selection for Alarm
Area2
01 Send/read Extended selection for Alarm
Area2
02 Send/read Both selection for Alarm Area2
0161 00 Send/read GPS Auto TX OFF
01 Send/read 5 sec. selection for GPS Auto
TX interval
02 Send/read 10 sec. selection for GPS Auto
TX interval
03 Send/read 30 sec. selection for GPS Auto
TX interval
04 Send/read 1 min. selection for GPS Auto
TX interval
05 Send/read 3 min. selection for GPS Auto
TX interval
06 Send/read 5 min. selection for GPS Auto
TX interval
07 Send/read 10 min. selection for GPS Auto
TX interval
08 Send/read 30 min. selection for GPS Auto
TX interval
0162 00 Send/read Disable selection for GPS TX
Mode
01 Send/read GPS selection for GPS TX
Mode
02 Send/read GPS-A selection for GPS TX
Mode
0163 00 Send/read GPS Sentence (RMC) OFF
01 Send/read GPS Sentence (RMC) ON
0164 00 Send/read GPS Sentence (GGA) OFF
01 Send/read GPS Sentence (GGA) ON
D Command table (continued)
Cmd. Sub cmd. Data Description
1A 05 0165 00 Send/read GPS Sentence (GLL) OFF
01 Send/read GPS Sentence (GLL) ON
0166 00 Send/read GPS Sentence (GSA) OFF
01 Send/read GPS Sentence (GSA) ON
0167 00 Send/read GPS Sentence (VTG) OFF
01 Send/read GPS Sentence (VTG) ON
0168 00 Send/read GPS Sentence (GSV) OFF
01 Send/read GPS Sentence (GSV) ON
0169 see p. 193 Send/read Unproto Address
0170 00 Send/read position data extension OFF
01 Send/read Course/Speed selection for
position data extension
0171 00 Send/read Time Stamp OFF
01 Send/read DHM selection for Time Stamp
02 Send/read HMS selection for Time Stamp
0172 00 to 16 Send/read GPS-A Symbol
(00=Ambulance,01=Bus,02=FireTruck,
03=Bicycle,04=Yacht,05=Helicopter,
06=SmallAircraft,07=Ship,08=Car,
09=Motorcycle,10=Balloon,11=Jeep,
12=RV,13=Truck,14=Van,
15=HouseQTH(VHF),16=Other)
0173 see p. 193 Send/read GPS-A Symbol Other
0174 00 to 16 Send/read GPS-A SSID
(00=--,01=(-0),02=-1to16,-15)
0175 see p. 193 Send/read Comment
0176 see p. 193 Send/read Comment (Extension)
0177 see p. 193 Send/read GPS TX Message
06 see p. 193 Send/read DATA mode selection
07 see p. 196 Send/read Satellite memory contents
1B 00 see p. 193 Send/read Repeater tone frequency
01 see p. 193 Send/read Tone squelch frequency
02 see p. 193 Send/read DTCS code and polarity
07 see p. 193 Send/read CSQL code (DV mode)
1C 00 00 Send/read Transceiver’s status (RX)
01 Send/read Transceiver’s status (TX)
01 00 Send/read Antenna tuner OFF (through)
01 Send/read Antenna tuner ON
02 Send/read Manual tuning selection
02 00 Send/read Transmit frequency monitor
check OFF
01 Send/read Transmit frequency monitor
check ON
1E 00 Read number of available TX frequency
band
01 see p. 191 Read TX band edge frequencies
02 Read number of user-set TX frequency
band
03 see p. 191 Send/read User-set TX band edge fre-
quencies
1F 00 see p. 193 Send/readDVMYcallsign
01 see p. 194 Send/read DV TX call signs
02 see p. 194 Send/read DV TX message
20 00 00 00*
2
Send/read Auto DV RX Callsigns output
OFF
01*
2
Send/read Auto DV RX Callsigns output
ON
01 see p. 194 Output DV RX Callsigns
02 see p. 194 Read DV RX Callsigns
01 00 00*
2
Send/read Auto DV RX message output
OFF
01*
2
Send/read Auto DV RX message output
ON
01 see p. 194 Output DV RX message
02 see p. 194 Read DV RX message
