Icom IC-9100 User Manual

191
18
CONTROL COMMAND
• Band edge frequency setting
Command 02*, 1E 01, 1E 03
q
XXX
w ertyuio!0!1!2
XXXXXXXXX2DXXXXXXXXXX
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–9 1 MHz digit: 0–9 1000 MHz digit: 0–1 100 MHz digit: 0–9 10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–9 1 MHz digit: 0–9 1000 MHz digit: 0–1 100 MHz digit: 0–9 Separator (fixed)
Lower edge Higher edge
Edge number*: 01–30
* Edge number setting is not necessary with com-
mand 02.
• Band stacking register
Command : 1A 01
q
XXXX
w
When sending the contents, the codes, such as op-
erating frequency and operating mode*, should be
added after the register code, as shown below.
* See t to %1 on ‘Memory content setting.’ (p. 195)
q Frequency band code
Code Freq. band Frequency range (unit: MHz)
01 1.8 1.800000– 1.999999
02 3.5 3.400000– 4.099999
03 7 6.900000– 7.499999
04 10 9.900000–10.499999
05 14 13.900000–14.499999
06 18 17.900000–18.499999
07 21 20.900000–21.499999
08 24 24.400000–25.099999
09 28 28.000000–29.999999
10 50 50.000000–54.000000
11 VHF 108.000000–174.000000
12 UHF 420.000000–480.000000
13 1.2G 1240.000000–1320.000000
14 GENE Other than above
w Register code
Code Registered No.
01 1 (latest)
02 2
03 3 (oldest)
For example, when reading the oldest contents in the
21 MHz band, the code “0703” is used.
• Memory keyer contents
Command : 1A 02
X
q: Channel data
w–&1: Text data
XXX
……
XX
01：M1
02：M2
03：M3
04：M4
•Character’scode
Character ASCII code Description
0–9 30–39 Number
A–Z 41–5A Alphabetical characters
a–z 61–7A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
, 2C Symbol
. 2E Symbol
@ 40 Symbol
^ 5E
e.g., to send BT, enter ^BT
✱
2A Inserts contest number (can be
used for 1 channel only)
• CW message contents
Command : 17
Set a CW message of up to 30 characters.
•Character’scode
Character ASCII code Description
0–9 30–39 Number
A–Z 41–5A Alphabetical characters
a–z 61–7A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
. 2E Symbol
– 2D Symbol
, 2C Symbol
: 3A Symbol
’ 27 Symbol
( 28 Symbol
) 29 Symbol
= 3D Symbol
+ 2B Symbol
” 22 Symbol
@ 40 Symbol
• “FF” stops sending CW messages.
• “^” is used to transmit a string of characters with
no inter-character space.
D Data content description (continued)
