Icom IC-9100 User Manual

12
1
PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
!8 USB (Universal Serial Bus) PORT [USB]
Using a USB cable, connect a PC to do the follow-
ing:
- Input modulation (p. 167)
- Remotely control the transceiver using CI-V com-
mands (p. 183)
- Send the received audio to the PC
- Send the decoded characters to the PC
(pp. 59, 167)
- Low-speed data communication in the DV mode
(p. 167)
- Cloning using the optional CS-9100 c l o n i n g s o f t -
w a r e (p. 182)
 •TwoCOMportnumbersareassignedtothe[USB]con-
nector. One of them is “USB1,” used for cloning and
CI-V operation. The other one is “USB2,” whose function
is selected in “USB2/DATA1 Func” (63) item of the Set
mode. (p. 167)
About the USB driver:
The USB driver and the installation guide can be
downloaded from our website.
➥ http://www.icom.co.jp/world/index.html
The following items are required:
PC
 •Microsoft
®
Windows
®
XP,
Microsoft
®
Windows Vista
®
or
Microsoft
®
Windows
®
7 OS
 •AUSB1.1or2.0port
Other items
 •USBcable(purchaseseparately)
 •PCsoftware(such as optional RS-BA1or CS-
9100)
NEVER connect the transceiver to a PC until the
USB driver installation has been completed.
About the modulation input:
Select “USB” in the Set mode item “DATA OFF
MOD” or “DATA MOD.” The modulation input level
from the USB jack can be set in the Set mode item
“USB MOD Level.” (p. 167)
