Icom IC-R30 User Manual

7
OTHER FUNCTIONS
7-32
■ CI-V information (Continued)
D Command table
Cmd. Sub cmd. Data Description
00 See p. 7-36 Output the frequency data for transceive
01 See p. 7-36 Output the receive mode for transceive
03 See p. 7-36 Read the receive frequency
04 See p. 7-36 Read the receive mode
05 See p. 7-36 Set the receive frequency
06 See p. 7-36 Select the receive mode
07 D0 Select the A band
(In the Dual band display, set the MAIN band to the A band.)
D1 Select the B band
(In the Dual band display, set the MAIN band to the B band.)
0C Read offset frequency
0D See p. 7-37 Set offset frequency
0F 10 ~ 12 Read duplex setting
(10=OFF, 11=DUP–, 12=DUP+)
10 Set Simplex
11 Set Duplex –
12 Set Duplex +
11* 00/15/30/45 Send/read Attenuator
(00=OFF, 15=ATT1, 30=ATT2, 45=ATT3)
12* 00/01 Select antenna
495 kHz ~ 1.620 MHz:
(00=Only external antenna, 01=Internal bar antenna)
Other than 495 kHz ~ 1.620 MHz:
(00=Only external antenna, 01=External antenna and earphone antenna)
14* 01 0000 ~ 0255 Send/read the AF gain level
(0000=Minimum ~ 0255=Maximum)
02 0000 ~ 0255 Send/read the RF gain level
(0000=Minimum ~ 0255=Maximum)
03 0000 ~ 0255 Send/read the squelch level
(0000=Minimum ~ 0255=Maximum)
15 01 00/01 Read noise or S-meter squelch status
(00=Close, 01=Open)
02 0000 ~ 0255 Read the S-meter level
(0000=S0, 0170=S9)
05 00/01 Read various squelch function’s (including the tone squelch) status
(00=Close, 01=Open)
16* 22 00/01 Send/read the Noise blanker function status
(00=OFF, 01=ON)
43 00 ~ 02 Send/read the Tone squelch status
(00=OFF, 01=ON, 02=TSQL-R)
4A 00/01 Send/read the AFC function status
(00=OFF, 01=ON)
4B 00 ~ 02 Send/read DTCS setting
(00=OFF, 01=ON, 02=DTCS-R ON)
4C 00/01 Send/read the VSC function setting
(00=OFF, 01=ON)
52 00/01 Send/read the P25 digital squelch (D.SQL) setting
(00=OFF, 01=NAC)
59 00/01 Send/read the display type
(00=Single band display, 01=Dual band display)
5B 00/02 Send/read the D-STAR digital squelch (D.SQL) setting
(00=OFF, 02=CSQL)
5F 00 ~ 02 Send/read the dPMR digital squelch (D.SQL) setting
(00=OFF, 01=COM ID, 02=CC)
*(Asterisk) Send/read data
