MD320/MD320N User Manual Parameter Description
103
When the automatic tuning of the motor is normally completed, the setup values of F1-06 to
F1-10 will be automatically updated.
Each time when the rated power of the motor F1-01 is changed, the inverter will automatically
recover the parameter values of F1-06 to F1-10 to the default standard motor parameters.
(Four-pole Y series asynchronous motor)
If it is impossible to tune the motor on the site, the user can manually input the parameters by
referring to the known parameters of the motors of the same type.
F1-11
Tuning selection Factory default value 0
Setup range
0 No operation
1 Static tuning
2 Complete tuning
be conducted because it is not easy to disconnect the motor from the load.
Action description: Set the function code to 1 and press RUN key for conrmation, and then the
inverter will conduct static tuning.
2. Complete tuning
To ensure the dynamic control performance of the inverter, please select rotary tuning. During
the rotary tuning, the motor must be disconnected with the loads (i.e. no-load).
Upon selection of rotary tuning, the inverter will conduct static tuning at rst. Upon completion
of static tuning, the motor will accelerate to 80% of the rated motor frequency in accordance
with the setup acceleration time of F0-17 and maintain for certain period of time. Then the
motor will decelerate to zero speed in accordance with the setup acceleration time of F0-18,
and by this time the rotary tuning is completed.
Action description: Set the function code to 2 and press RUN key for conrmation, and then the
inverter will conduct rotary tuning.
F1-06
Stator resistance Factory default value Model dependent
Setup range 0.001Ω~ 65.535Ω
F1-07
Rotor resistance Factory default value model dependent
Setup range 0.001Ω~ 65.535Ω
F1-08
Leakage inductive
reactance
Factory default value model dependent
Setup range 0.01mH ~ 655.35mH
F1-09
Mutual inductive
reactance
Factory default value model dependent
Setup range 0.1mH ~ 6553.5mH
F1-10
No-load current Factory default value model dependent
Setup range 0.01A~ 650.00A
