Parameter Description MD320/MD320N User Manual
120
F5-00
FM terminal output mode
selection
Factory default value 0
Setup range
0 Pulse output (FMP)
1 Collector open output (FMR)
FM terminal is programmable multiplexing terminal.
It can be used as high-speed pulse output (FMP), with maximum frequency of 50 kHz. Refer to
F5-06 for relevant functions of FMP.
It can also be used as collector open output terminal (FMR). Refer to F5-01 for FMR function.
F5-01
FMR output selection
(collector open output
terminal)
Factory default value 0
F5-02
Control board RELAY 1
output selection (T/A-T/
B-T/C)
Factory default value 2
F5-03
Expansion card RELAY 1
output selection (P/A-P/
B-P/C)
Factory default value 0
F5-04
DO1 output selection
(collector open output
terminal)
Factory default value 1
F5-05
Expansion card DO2
output selection
Factory default value 4
Caution: RELAY 1 and RELAY2 refer to TA/TB/TC;
Multifunctional output terminal function selection is as follows:
output expansion card can be used.
The multifunctional input and output expansion card has additional one multifunctional
relay output terminal (relay 2), one multifunctional digital output terminal (DO2) and one
multifunctional analog output terminal (AO2).
Setup
value
Function Description
0 no output The output terminals does not have any function.
1
Inverter is
running
It indicates the inverter is running, and there is output frequency
(can be zero), and ON signal will output at this time.
