MD320/MD320N User Manual Appendix
183
83mm
80mm
JK4
JK3
CN2
Locating hole
CN1
JK1
CN3
83mm
80mm
JK4
JK3
CN2
Expansion
card interface
CN1
JK1
CN3
Thre e
Mounting hole
Appendix C: Fig.2 Physical Dimensions
JK3
0/4-20mA
0-10V
JK4
I V
Appendix C: Fig.3 Jumper Terminal
C.2.2 Description of Control Terminal Function:
