Fig.3-3 Removing the Down Cover Plate of Plastic Enclosure
The MD series inverter of more than 18.5kW employs sheet-metal enclosure. Please refer to
Figure 3-4 for removing the lower cover plate of the sheet-metal enclosure. It is easy to loosen
the screws of the upper cover plate with tools.
Danger
When removing the down cover plate, be sure to avoid the falling of the down

cover, which may cause human injury or damage to the equipment.
Fig.3-4 Removing the Lower Cover Plate of Sheet-Metal Enclosure
