Appendix MD320/MD320N User Manual
184
Appendix C: Table 1 Control Terminal Function
Type
Terminal
Symbol
Terminal
name
Function description
Power
supply
+10V-GND +10V-GND
Provide +10V power supply for external units,
with maximum output current of 10mA.
It is generally used as the operating power
supply for the external potentiometer. The
potentiometer resistance range is 1kΩ
to10kΩ.
+24V-COM
External
+24V power
supply
Provide +24V power supply for external units.
It is generally used as the operating power
supply for digital input/output terminal and the
external sensor.
The maximum output current is 200mA.
OP
Operating
power
terminal of IO
port
Prior to delivery, the OP is connected to
“+24V” with short circuit copper bar.
When it needs external power supply, OP
shall be connected with the external power
supply, and the short circuit copper bar shall
be removed.
Analog
Input
AI3-GND
Analog input
terminal 3
1. Input voltage range: DC 0V to 10V/4mA to
20mA, which is determined by JK3 jumper on
the expansion card (the factory default value
is 0V to 10V).
2. Input impedance: It is 100kΩ at the time of
voltage input and 500Ω at the time of current
input.
Functional
digital input
terminal
DI6-COM Digital input 6
1
、
Optical coupling isolation,compatible with
dual polarity input
2
、
Input impedance: 3.3Kω
3
、
Voltage range for level input:9V to 30V
DI7-COM Digital input 7
DI8-COM Digital input 8
DI9-COM Digital input 9
DI10-COM
Digital input
10
Analog out AO2-GND
Analog
output 2
The voltage or current output is determined
by the JK4 jumper on the expansion card (the
factory default value is voltage output).
Output voltage specication: 0V to 10V
Output current specication: 0mA to 20mA
