1) The bottom-layer module of the MD series inverter is high-performance motor control
module and consists of V/F, speed sensorless vector control (SVC) and vector control. It is
mainly responsible for high performance control and overall protection of the motor, controlling
the motor through sending running commands to multiple channels or performing close loop
vector control through encoder interface.
2) The middle-layer module of MD series inverter is general functional module, which mainly
includes some basic functions of the inverter, such as PID control, MS speed, and swing
frequency and so on. According to the degree of complexity of functions, Inovance Technology
provides two sub-modules for options of the customers, that is, MD320 functional module and
MD300 functional module. Refer to Table 1 for the difference between the two modules.
Table 1 Difference between MD320 and MD300 Functional Modules
MD320 MD300
Input/output terminal
Five DI (bidirectional input
and one high-speed port), two
AI, two DO (one high-speed
port), one AO, and one relay
(expandable I/O)
Four DI (unidirectional input
and one high-speed port), two
AI, one DO, one AO, and one
relay
Control mode SVC
、
VC
、
V/F SVC
、
V/F
Analog setup mode Straight line mode
Multiple-point fold line mode,
which is easy to realize the
functions of the injection
molding machine
MS speed Be able to realize 16S speed Be able to realize 4S speed
PLC Simple PLC
Be able to realize 16S timing
operation
None
Swing frequency and
xed-length control
Available None
Main/auxiliary setup
Main/auxiliary reference of
any channel
Only A12 can be auxiliary setup
Communication function Via the expansion card Via the specialized card
PID control Available None
Multiple-point V/F Available None
