– 23 –
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the
following work after turning the power o and ascertaining that the motor is at rest.
3-5. Threading the machine head
1) Turn the handwheel by hand to bring the needle to the most raised position.
2) Pass the thread in the order of the numbers as illustrated.
3) For threading portion
, the thread take-up lever is threaded by guiding the thread along the
groove.
4) Pull out the thread about 10 cm from the needle after passing it through the needle.
Thread take-up
With thread
trimmer
Without thread
trimmer
Turn the
thread once.
To Next Page
