– 1 –
Model LZ-2290CF-7
Application Light-weight materials to medium-weight materials
Max. sewing speed 5,000 sti/min (*1)
Max. zigzag width 10 mm (*2)
Max. feed pitch 5 mm (normal/reverse feed) (*3)
Stitch pattern 15 kinds 21 patterns
Needle SCHMETZ 438 #75 (Needle at the time of delivery)
Lubricating oil JUKI New Defrix Oil No. 1
Multi-layered portion detection function With
Horizontal feed control Electronic control
Alternate vertical feed control Electronic control
Active tension function With
Thread trimmer With
Wiper method Front sweeping method
Noise
- Equivalent continuous emission sound pressure level (L
pA
) at the
workstation :
A-weighted value of 81.5 dB; (Includes K
pA
= 2.5 dB); according to ISO
10821- C.6.2 -ISO 11204 GR2 at 4,000 sti/min.
1. SPECIFICATIONS
1-1. Specications of the sewing machine head
1-2. Specications of the control box
Model SC-955A
Supply
voltage
Single phase
100 to 120V
3-phase
200 to 240V
Single phase
220 to 240V
Single phase
220 to 240V CE
Frequency 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz 50Hz/60Hz
Operating
environment
Temperature : 0 to 35˚C
Humidity : 90% or less
Temperature : 0 to 35˚C
Humidity : 90% or less
Temperature : 0 to 35˚C
Humidity : 90% or less
Temperature : 0 to 35˚C
Humidity : 90% or less
Input 600VA 600VA 600VA 600VA
* 1. The max. sewing speed is set to 4,000 sti/min at the time of delivery (depending on the delivery area).
•
The speed is limited by setting of the zigzag width of the sewing pattern and feed amount since the speed is
controlled by the amount of zigzag width per stitch and feed amount.
•
Properly set the number of revolution in accordance with the product to be sewn and process.
* 2. Max. zigzag width is limited to 8 mm at the time of standard delivery.
* 3. Standard feed amount has been factory-set to 2.5 mm at the time of shipment.
