– 37 –
4-9. Mirror stitching
The mirror inversion is the function for sewing a pattern that is inverted during sewing. When the custom
switch (i09: Already allocated with the function for inputting the mirror inversion switch) is pressed during
sewing, the sewing machine starts sewing while inverting the sewn pattern. (Refer to
"4-8. Custom switch"
p.35
for details.)
Sewing procedure (Example : scallop)
Sewing
direction
Scallop 1
pattern
Afterwards
inversion
operation
Mirror inver-
sion operation
is displayed
on the opera-
tion panel
Pattern during sewing
Stop the sewing machine.
Press the custom switch.
3) Perform mirror inversion sewing with the sew-
ing machine.
4) Perform thread trimming or press again the
mirror inversion switch to complete the inver-
sion sewing.
1) Stop the sewing machine at the position you
desire to perform mirror inversion during sew-
ing.
2) Press the custom switch (i09: Already allo-
cated with the function for inputting the mirror
inversion switch). Once the sewing machine
accepts the input of the mirror inversion
switch, is displayed on the upper portion
of operation panel.
(The switch can receive only when the sew-
ing machine stops and dose not receive when
the sewing machine is running.)
Mirror function setting
For the mirror inversion, there are two settings below.
1) 1 pattern : Mirror inversion is “1” pattern
only. After completion of inversion pattern, the
pattern returns to the original one.
2) Continuous : The machine continuously
operates the inversion pattern after the inver-
sion until thread trimming is performed or, the
mirror switch is pressed again.
Sewing direction
Custom switch
is turned ON
Pattern mode
Continuous mode
is displayed on
the operation panel
is displayed
on the operation
panel
To Next Page
