– 77 –
5-2-11. Narrow-down function
It is possible to select and display sewing pattern(s) which include target characters from the sewing patterns
stored in memory by entering the target characters such as the product number, process or comment. This
function can be used both under the operator mode and maintenance personnel mode.
Selecting the new-pattern creating function
1) Press
to display the "sewing pat-
tern management screen".
<Sewing pattern management screen>
2) Press
.
<Sewing screen (maintenance personnel mode)>
Select the target pattern to be narrowed down
1) Select sewing patterns from which a de-
sired pattern is narrowed down using but-
ton
.
2) The character input screen is displayed by
pressing
.
It is possible to enter a character(s) which is
to be used for narrow-down operation with
the character string button.
3) The entered characters are erased by press-
ing button
.
<Narrow-down condition setting screen>
4) The "Sewing pattern management screen" containing only the patterns which include the entered char-
acter(s) are displayed by pressing
.
5) Narrow-down operation is not carried out by pressing
. Then, the "Sewing pattern management
screen" is displayed.
* In the case characters are entered for two or more items on the narrow-down condition setting screen,
only the patterns which satisfy all the entered conditions are displayed. For cycle sewing patterns, a com-
ment is only used as the narrow-down condition.
To Next Page
