Juniper EX2300 Series Hardware Guide

RJ-45 Network Port LEDs and Uplink Port LEDs in EX2300 Switches
Each RJ-45 network port and uplink port on the front panel of EX2300 switches except the
EX2300-24MP and EX2300-48MP switch models have two LEDs that indicate link/acvity and port
status. See Figure 24 on page 34, Figure 25 on page 34, and Figure 26 on page 35.
Figure 24: LEDs on RJ-45 Network Ports on EX2300 Switches Except the EX2300-24MP and
EX2300-48MP Switch Models
Figure 25: LEDs on the Uplink Ports in EX2300-C Switches
34
