CHAPTER 1
System Overview
•
SRX345 Services Gateway Description on page 3
SRX345 Services Gateway Description
The SRX345 Services Gateway consolidates security, routing, switching, and WAN
interfaces for midsize distributed enterprises. With advancedthreat mitigation capabilities,
the services gateway provides cost-effective and secure connectivity across distributed
enterprises. The services gateway simplifies network complexity, protects and prioritizes
network resources, and improves user and application experience.
The SRX345 Services Gateway has a capacity of 5 gigabits per second (Gbps) and is 1
rack unit (U) tall. The services gateway has eight 1 G Ethernet ports, eight 1 G SFP ports,
one management port, 4 GB of DRAM memory, 8 GB of flash memory, and four
Mini-Physical Interface Module(Mini-PIM) slots. The chassis installs in standard800–mm
(or larger) enclosed cabinets, 19 in. equipment racks,or telecommunications open-frame
racks.
Figure 1 on page 3 shows the SRX345 Services Gateway.
Figure 1: SRX345 Services Gateway
The SRX345 ServicesGatewayruns the Junos operating system (Junos OS). The following
are a few of the features supported:
•
Firewall support with key features such as VPN
•
Intrusion Detection and Prevention (IDP), AppSecure, and UTM
•
High availability
•
QoS
•
MPLS
3Copyright © 2017, Juniper Networks, Inc.
