Juniper SRX345 Hardware Guide

CHAPTER 5
Power System Description
•
Understanding the SRX345 Services Gateway Power Supply on page 15
Understanding the SRX345 Services Gateway Power Supply
The SRX345 Services Gateway uses a fixed, internal AC power supply. The power supply
distributes the different output voltages to the device components according to their
voltage requirements. The power supply is fixed in the chassis and is not field-replaceable.
The power supply has a single AC appliance inlet that requires a dedicated AC power
feed.
NOTE: The services gateway is availablewith either a single AC power supply
or dual AC power supplies.
Related
Documentation
• SRX345 Services Gateway Chassis Overview on page 5
• Understanding the SRX345 Services Gateway Front Panel on page 5
• Understanding the SRX345 Services Gateway Back Panel on page 8
• SRX345 Services Gateway Power Specifications and Requirements on page 34
15Copyright © 2017, Juniper Networks, Inc.

Juniper SRX345 Specifications

General

USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	8
Flash memory	8000 MB
Internal memory	4000 MB
Certification	FCC A, RoHS 2
Rack capacity	1U
Heat dissipation	420 BTU/h
Power consumption (typical)	122 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, MPLS, OSPF, RIP-1, RIP-2
Supported network protocols	IPv4, IPv6
Firewall security	Yes
Security algorithms	IPSEC, SSL/TLS
Networking standards	IEEE 802.1p
Ethernet LAN data rates	10, 100, 1000 Mbit/s

Weight and Dimensions

Weight	4900 g
Dimensions (WxDxH)	440.9 x 370.1 x 43.6 mm
