Juniper SRX345 Hardware Guide

CHAPTER 10
Cable Specifications and Pinouts
•
RJ-45 Connector Pinouts for the SRX345 Services Gateway Ethernet Port on page 37
•
RJ-45 Connector Pinouts for the SRX345 Services Gateway Console Port on page 37
•
Mini-USB Connector Pinouts for the SRX345 Services Gateway Console Port on page 38
RJ-45 Connector Pinouts for the SRX345 Services Gateway Ethernet Port
Table 13 on page 37 describes the RJ-45 connector pinouts for the Ethernet port.
Table 13: RJ-45 Connector Pinouts for the SRX345 Services Gateway
Ethernet Port
SignalPin
BI_DA+1
BI_DA2
BI_DB+3
BI_DC+4
BI_DC5
BI_DB6
BI_DD+7
BI_DD8
Related
Documentation
RJ-45 Connector Pinouts for the SRX345 Services Gateway Console Port on page 37•
• Mini-USB Connector Pinouts for the SRX345 Services Gateway ConsolePort on page 38
RJ-45 Connector Pinouts for the SRX345 Services Gateway Console Port
Table 14 on page 38 describes the RJ-45 connector pinouts for the console port.
37Copyright © 2017, Juniper Networks, Inc.

Juniper SRX345 Specifications

General

USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	8
Flash memory	8000 MB
Internal memory	4000 MB
Certification	FCC A, RoHS 2
Rack capacity	1U
Heat dissipation	420 BTU/h
Power consumption (typical)	122 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, MPLS, OSPF, RIP-1, RIP-2
Supported network protocols	IPv4, IPv6
Firewall security	Yes
Security algorithms	IPSEC, SSL/TLS
Networking standards	IEEE 802.1p
Ethernet LAN data rates	10, 100, 1000 Mbit/s

Weight and Dimensions

Weight	4900 g
Dimensions (WxDxH)	440.9 x 370.1 x 43.6 mm
