CHAPTER 3
Interface Module Descriptions
•
SRX345 Services Gateway Interface Modules Overview on page 11
SRX345 Services Gateway Interface Modules Overview
Mini-Physical Interface Modules (Mini-PIMs) are field-replaceable network interface
cards (NICs) supported on the SRX300 line of services gateways. You can easily insert
or remove Mini-PIMs from the front slots of the services gateway chassis. The Mini-PIMs
provide physical connections to a LAN or a WAN. The Mini-PIMs receive incoming packets
from the network and transmit outgoing packets to the network. During this process,
they perform framing and line-speed signaling for the medium type.
CAUTION: The Mini-PIMs are not hot-swappable. You must power off the
services gateway before removing or installing Mini-PIMs.
The following Mini-PIMs are supported on the SRX345 Services Gateway:
•
1-Port Serial Mini-Physical Interface Module (SRX-MP-1SERIAL-R)
•
1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R)
•
1-Port VDSL2 (Annex A) Mini-Physical Interface Module (SRX-MP-1VDSL2-R)
•
LTE Mini-Physical Interface Module (SRX-MP-LTE-AE and SRX-MP-LTE-AA)
NOTE: Gigabit-Backplane Physical Interface Modules (GPIMs) are not
supported on the SRX345 Services Gateway.
For more information on the Mini-PIMs, see SRX300 Series and SRX550 High Memory
Gateway Interface Modules Reference.
Related
Documentation
• SRX345 Services Gateway Chassis Overview on page 5
• Understanding the SRX345 Services Gateway Front Panel on page 5
11Copyright © 2017, Juniper Networks, Inc.
