Digital Video Cassette Technology
92
Data Dump Definition
This section describes the definitions for the Data Dump in the Inspector window.
Standard Dump
Page 0
Byte Definition Other
1 IR Flicker
2 Setting of Data Read Out Of EEPROM (EVR)
3 IR Sensor Voltage
4 Hall Element Voltage
5 Hall Element Voltage Regulation
6 Electronic Zoom Operation See Table 10
7 Focus Lens (Master Lens) Position Low-Order Byte
8 Focus Lens (Master Lens) Position High-Order Byte
9 Zoom Lens Position Low-Order Byte
10 Zoom Lens Position High-Order Byte
11 Focus Operation BPF (H) Voltage Low-Order Byte
12 Focus Operation BPF (H) Voltage High-Order Byte
13 Focus Control See Table 11
14 Iris Control See Table 12
15 White Balance Control See Table 13
16 Camera Shake Detection See Table 14
17 AGC Level Regulation
18 Focus Sensor Voltage
19 Zoom Sensor Voltage
20 Focusing Operation See Table 15
21 AE Operation See Table 16
22 White Balance Operation See Table 17
23 Red Gain For White Balance
24 Blue Gain For White Balance
25 Shutter Speed Low-Order Byte See Table 18
26 Shutter Speed High-Order Byte See Table 18
27 PWM Voltage Low-Order Byte
28 PWM Voltage High-Order Byte
29 OB1 Low-Order Byte
30 OB1 High-Order Byte
31 OB2 Low-Order Byte
32 OB2 High-Order Byte
Table 9 Data Dump - Standard Mode, Page 0
