OPERATION
OPERATION
STEERING MACHINE
WARNING
Avoid as much as possible turning the machine on a slope.
The machine will tend to slip sideways. Particular care should be taken on soft or clay land.
Never make a pivot turn at high speed.
NORMAL TURNING
To turn the machine while traveling, incline joystick (1) in the
direction to turn.
TURNING TO LEFT WHILE TRAVELING FORWARD
If the joystick is pushed forward and moved partially to the left (L),
the steering clutch is disengaged and the machine turns gradually
to the left.
When turning gradually to the right, push the joystick forward, and
move it partially to the right.
Do the same when traveling in reverse.
3 - 104
