ATTACHMENTS, OPTIONS
CAP WITH LOCK, HANDLING
CAP WITH LOCK, HANDLING
METHOD OF OPENING AND CLOSING CAP WITH LOCK
Lock-type caps are available for the radiator water filler, fuel tank filler cap, power train case oil filler cap, hydraulic
tank oil filler cap, and hydraulic tank breather cap. The method of opening or closing the cap is as follows.
TO OPEN THE CAP
1.
Insert the key.
Insert the key fully up to the shoulder before turning it. If the
key is inserted half way and turned, the key may break.
2.
Turn the key counterclockwise to align the match mark on the
cap with the rotor groove, then turn the cap slowly. When a
click is heard, the lock is released, enabling the cap to be
opened.
TO LOCK THE CAP
1.
Turn the cap into place.
2. Turn the key clockwise and take the key out.
6 - 5
