MAINTENANCE
WEAR PARTS LIST
WEAR PARTS LIST
Wear parts such as the filter element, air cleaner element etc. are to be replaced at the time of periodic maintenance
or before their abrasion limits.
The wear parts should be changed correctly in order to use the machine economically.
When changing parts,use Komatsu genuine parts of excellent quality.
When ordering parts, please check the part number in the parts book.
WEAR PARTS LIST
The parts in parentheses are to be replaced at the same time.
Item Part No. Part Name
Weight
(kg(lb))
Q'ty
Replacement
frequency
Engine oil filter 600-211-1340 Cartridge - 1
Every 500
hour service
Power train filter
07063-01100
(07000-02130)
Element
(O-ring)
-
-
1
(1)
Fuel filter 600-311-3310 Cartridge - 1
Hydraulic tank breather 20Y-60-21470 Cap element - 1
Corrosion resistor 600-411-1161 Cartridge - 1
Every 1000
hours service
Charge filter
07063-51054
(07000-02110)
Element
(O-ring)
-
-
1
(1)
Hydraulic oil filter
07063-51100
(07000-02130)
Element
(O-ring)
-
-
1
(1)
Every 2000
hours service
Air cleaner
600-185-6100 Element ass'y - 1
-
600-185-6110 Outer element ass'y 1
Air conditioner
Fresh filter 14X-911-7750 Filter - 2
-
Recirc filter 20Y-979-6261 Filter - 1
Blade
Semi U-dozer
195-70-12492
17A-71-11351
17M-71-21930
17M-71-21940
17A-71-12451
17M-71-21530
Cutting edge
Cutting edge
End bit (left)
End bit (right)
(Bolt)
(Nut)
103.4 (228)
57 (126)
63 (139)
63 (139)
-
-
1
2
1
1
(33)
(33)
-
U-dozer
17A-72-12221
17M-72-21160
17M-71-21930
17M-71-21940
17A-71-12451
17M-71-21530
Cutting edge
Cutting edge
End bit (left)
End bit (right)
(Bolt)
(Nut)
69 (152)
58 (128)
63 (139)
63 (139)
-
-
2
2
1
1
(36)
(36)
-
Angledozer
175-70-26310
175-70-21115
175-71-11454
175-71-11530
175-70-21126
175-70-21136
175-71-11463
175-71-11530
Cutting edge
Cutting edge
(Bolt)
(Nut)
End bit (left)
End bit (right)
(Bolt)
(Nut)
48.8 (108)
64.1 (141)
-
-
37 (82)
37 (82)
-
-
1
2
(25)
(25)
1
1
(14)
(14)
-
Ripper
Multi
175-78-31230
195-78-21320
09244-02508
Point
Protector
(Pin)
15 (33.08)
13 (28.67)
-
3
3
(9)
-
Giant
175-78-31230
195-78-21320
09244-02508
Point
Protector
(Pin)
15 (33.08)
13 (28.67)
-
1
1
3
-
NOTICE
When handling parts that weigh more than 25 kg (55 lb), remember that they are heavy objects, and take the necessary care.
4 - 9
