OPERATION
TRANSPORTATION
REMOVAL OF CAB
(Machines equipped with cab)
If it is necessary to remove the cab for transporting, disconnect the
washer hoses, cab power source, and washer motor wiring from
the socket before removing the cab.
1.
Pull the grommet portion in towards the cab from the hole in the
machine cover, then remove.
2.
Disconnect the 4 washer hoses and electric wires (2 single
wires, 1 4-pin socket) from the socket.
3. When removing the cab, carry out the operation according to
the cab installation manual held by your Komatsu distributor.
REMARK
After removing, cover with vinyl bag to prevent dirt or dust from
entering the washer hose.
Before removing the cab, check the clearance between the cab
and the levers, and use for information as reference for
confirming the position when installing the cab.
3 - 133
