13 SERVICE WORK ON THE CHASSIS
144
13.16 Adjusting the chain tension
Warning
Danger of accidents Incorrect chain tension damages components and results in accidents.
If the chain is tensioned too much, the chain, engine sprocket, rear sprocket, transmission and rear
wheel bearings wear more quickly. Some components may break if overloaded.
If the chain is too loose, the chain may fall off the engine sprocket or the rear sprocket. As a result, the
rear wheel locks or the engine will be damaged.
– Check the chain tension regularly.
– Set the chain tension in accordance with the specification.
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 129)
– Check the chain tension. ( p. 142)
S01107-10
Main work
–
Loosen screw
1
.
– Set the chain tension by turning the hub housing.
Holding wrench (61329085000)
Handle for holding wrench (60012060000)
