TECHNICAL DATA 23
259
rear: with cold tires 2.9 bar (42 psi)
Secondary drive ratio 17:38
Chain 5/8 x 5/16” (525) X‑ring
Steering head angle 65.1°
Wheelbase 1,482 ± 15 mm (58.35 ± 0.59 in)
Seat height unloaded 835 mm (32.87 in)
Ground clearance unloaded 141 mm (5.55 in)
Weight without fuel approx. 213 kg (470 lb.)
Maximum permissible front axle load 165 kg (364 lb.)
Maximum permissible rear axle load 320 kg (705 lb.)
Maximum permissible overall weight 456 kg (1,005 lb.)
23.5 Electrical system
Battery YTZ14S Battery voltage: 12 V
Nominal capacity: 11.2 Ah
Maintenance-free
Fuse 58011109110 10 A
Fuse 58011109115 15 A
Fuse 58011109125 25 A
Fuse 58011109130 30 A
Low beam/high beam H4/socket P43t 12 V
60/55 W
