15 WHEELS, TIRES
176
15.2 Installing the front wheel
H01075-10
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change front wheel bearing.
–
Clean and grease shaft seal rings
1
and contact surfaces
A
of the spacers.
Long-life grease ( p. 277)
S01134-10
–
Insert wide spacer
2
on the left in the direction of travel.
Info
Arrow
B
indicates the direction of travel of the front
wheel.
The ABS sensor wheel is on the left viewed in the direc-
tion of travel.
– Insert the narrow spacer on the right in the direction of travel.
