6 CONTROLS
30
H01276-10
Overview of the left combination switch
1
Light switch ( p. 30)
2
Hazard warning flasher switch ( p. 31)
3
Menu switch ( p. 32)
4
Turn signal switch ( p. 32)
5
Horn button ( p. 33)
6.4.2 Light switch
E00158-10
The light switch
1
is fitted on the combination switch on the
left.
Possible states
Low beam on – Light switch in position
A
. In this
position, the low beam and the tail light are switched
on.
High beam on – Light switch in position
B
. In this
position, the high beam and the tail light are switched
on.
Headlight flasher – Light switch in position
C
. The
headlight flasher is operated in this position. The light
switch returns automatically to the position
A
after
use.
